Supreme Petrochem Ltd, part of Supreme Group of companies, is the largest producer of Polystyrene & Expandable Polystyrene beads in India, key raw materials for making Thermal Insulation Boards/Sheets. State-of-art manufacturing facilities are located in Nagothane, Maharashtra and Chennai, Tamilnadu.
Extruded Polystyrene (XPS) Thermal Insulation Board is a rigid foam board having closed cell structure and is produced in a fully automated continuous extrusion process in accordance with international specifications and standards. Its unique properties of high compressive strength, higher R value and low water absorption makes it an ideal insulating material for roofs, walls and floors.
The cost of energy and demand for air conditioning in buildings is constantly increasing. With increased energy conservation becoming more and more relevant, the ability of the product selected to effectively insulate a building of whatever type is very important.
Insulation should be viewed as a long term investment. Consequently, one of the best ways to optimize this investment is by choosing high quality and effective insulation material for buildings.
| Properties | Roof | Wall | Floor |
|---|---|---|---|
| Thermal Conductivity | 0.0289 W/mK | 0.0289 W/mK | 0.0289 W/mK |
| Density | > 34 Kg/m 3 | > 34 Kg/m 3 | > 38 Kg/m 3 |
| Compressive Strength | > 300 kPa (varies with thickness and ASTM class) | > 180 kPa (varies with thickness and ASTM class) | > 500 kPa (varies with thickness and ASTM class) |
Insuboard is a thermal insulation material that offers heat flow resistance, low thermal conductivity, and durability.
High heat resistance, long-term insulation, water-resistant, durable, uniform density, strong, lightweight.
Insuboard maintains its thermal conductivity and insulation properties over time, ensuring continuous energy conservation and efficiency.
Insuboard offers exceptional heat flow resistance and maintains its thermal conductivity value, even after long- term use, ensuring the necessary heat flow into or out of a system.
Insuboard’s closed cell structure offers superior resistance to water permeability, absorbing less than 1% of water by volume.
The material’s high density and compressive strength make it ideal for over- deck of floor insulation in cold storages.
Insuboard is tested according to DlN 4102 and is available in both class B2 & B1 for fire resistance.
Insuboard’s cellular composition is regular and homogeneous, ensuring good dimensional stability.
The Insu board is an ideal solution for energy conservation in various industries, commercial buildings, and private residential dwellings.
Insuboard insulation, with its thermal resistance and durability, can significantly reduce energy consumption, air conditioning demand in buildings, and make it economically viable.
